Metrostate Cyber Defense

Metrostate CCDC 2027

Click any component in the topology to jump straight into the matching ESXi console tab. All links open in a new browser tab.

Direct Access Deck

Plain list of every shortcut in case the topology overlay is blocked by a browser extension.

Humberto

Windows host

  • LAN: 172.16.101.82

Credentials

  • Administrator / LabAdmin1!
Open ESXi Console

Nikita

Windows host

Open ESXi Console

Connor

Windows host

Open ESXi Console

Resources

Quick shortcuts for shared tooling services.

Nextcloud

Team cloud drive and shared docs.

http://10.100.1.190/index.php/login

Open Resource

Enumeration Windows Files

Browse Windows-based enumeration drops.

http://10.100.1.190:9000/

Open Resource

Enumeration Files

General file drop for Linux/Unix enumeration.

http://10.100.1.190:8080

Open Resource

Dashboard Monitor

Monitoring dashboard for lab services.

http://10.100.1.200:8001/

Open Resource

Redteam Artifacts

Red team artifacts and file drops.

http://10.100.1.188:8081/

Open Resource

Injects

Competition injects and scoreboard.

https://scoreboard.4rji.com/

Open Resource

Network Core

Router, firewalls and the external Windows VM.

VyOS Router

Core routing node

  • External: 172.31.21.2/29
  • net1: 172.16.101.1/24
  • net2: 172.16.102.1/24
  • ESXi: 10.100.1.130

Credentials

  • vyos / changeme
Open ESXi Console

Palo Alto

Left-side firewall

  • Outside: 172.16.101.240/24
  • Inside: 172.20.242.254/24
  • Mgmt: 172.20.242.150

Credentials

  • admin / Changeme123
Open ESXi Console

Cisco FTD

Perimeter firewall

  • Outside: 172.16.102.254/24
  • Inside: 172.20.240.254/24
  • Mgmt: 192.168.45.45 (MGMT-FTD)
  • Mgmt: 172.20.240.200
  • VyOS: 172.16.102.33

Credentials

  • admin / Changeme123
Open ESXi Console

Windows 10 External

Use this VM to check external service IPs (DNS, webmail, websites, etc.).

Credentials

  • metro / no password
Open ESXi Console

Infrastructure Topology

VyOS Router Palo Alto Cisco FTD Humberto Nikita Connor

Additional Lab Machines

Extra hosts that sit outside the primary training deck but still need fast ESXi access.

kali-external

Ip eth0 10.100.1.189

Open ESXi Console

Debian Net2 network

Debian 24 workstation

  • ens160: 172.16.102.10
Open ESXi Console

Debian-Net1

Net1 Debian host

  • ens192: 172.16.101.13
Open ESXi Console

Kali on Palo Network

For testing connectivity and nmap scans

  • LAN: 172.20.242.69

Credentials

  • metro / metro
Open ESXi Console

Kali on Cisco Network 240

For testing connectivity and nmap scans

  • LAN: 172.20.240.89

Credentials

  • metro / metro
Open ESXi Console
